Albatross Ultraviolet lamp

Name: Albatross Ultraviolet lamp
Brand: ESINTI PRIVATE LIMITED
Price: 11711.0 INR
Availability: InStock

Price 11711.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Albatross Ultraviolet lamp Specification

Weight
Differ as per size Grams (g)

Product Type
Uv Lamp

Voltage
220 - 1900 Volt (v)

Dimension (L*W*H)
Customizable as per requirement Millimeter (mm)

Usage & Applications
Offset printing machines Flexographic printing presses Gravure printing systems Digital inkjet printing equipment Screen printing machines Packaging printing lines Label printing and finishing systems

Model No
Albatross

Automation Grade
Automatic

Warranty
Yes

Mounting
Standard and custom mounting compatible

Protection
Over-voltage and thermal cut-off included

Power Consumption
According to lamp length and type

Wavelength Range
200-400 nm

Ignition Type
Hot/Cold start compatible

Cooling
Air/Water cooled

Material
Quartz glass & aluminium housing

Surface Finish
Polished/Anodized

Lamp Life
8000-12000 hours

Albatross Ultraviolet lamp Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
1000 Pieces Per Year

Delivery Time
1 Days

Main Domestic Market
All India

About Albatross Ultraviolet lamp

Albatross Ultraviolet Lamp for Printing & UV Curing Applications

The Albatross Ultraviolet Lamp is a high-performance UV curing solution designed to deliver fast, uniform, and reliable curing of inks, coatings, and varnishes in industrial printing environments. Engineered for demanding production lines, this ultraviolet lamp ensures consistent curing quality across offset, flexographic, gravure, digital inkjet, screen, and packaging printing applications.

With stable UV output and precise energy distribution, the Albatross ultraviolet lamp improves print adhesion, color density, and surface durability while significantly reducing drying time. It is an ideal solution for high-speed printing machines where efficiency and print quality are critical.

Versatile Ultraviolet Lamp for Multiple Printing Methods

This industrial ultraviolet lamp is compatible with a wide range of printing technologies, including offset, flexo, gravure, digital inkjet, and screen printing. Its versatile design makes it suitable for commercial printers, label manufacturers, and packaging converters seeking dependable UV curing performance.

Technical Specifications Ultraviolet Lamp

Size	Total Length (mm)	Arc Length (mm)	Diameter (mm)	End Fitting Style	Terminal Type	Cable Length (Left mm)	Cable Length (Right mm)	Voltage	Current (A)	Power (KW)
25"/300	805	635	25	B	Pin Type	285	285	900	8.8	7.5
28"/300	812	711	25	B	Pin Type	285	285	1000	8.4	8.4
30"/300	914	762	25	B	Pin Type	285	285	1000	9.8	9
36"/300	1016	914	25	B	Pin Type	285	285	1200	9	10.8
40"/400	1168	1016	25	B	Pin Type	285	285	1500	10.6	16

Available in around 200 different sizes, with customized sizes also available.

Key Features of Albatross Ultraviolet Lamp

High-intensity ultraviolet lamp for fast and uniform curing
Suitable for multiple printing and coating applications
Stable UV output for consistent curing results
Designed for high-speed and continuous production
Long operational life with reliable performance
Wide range of standard and customized sizes available

Applications of Ultraviolet Lamp

Offset printing
Flexographic printing
Gravure printing
Digital inkjet printing
Screen printing
Packaging and label printing

FAQs Albatross Ultraviolet Lamp

Q1: What is the role of an ultraviolet lamp in printing?
A: An ultraviolet lamp instantly cures UV inks and coatings, reducing drying time, improving print quality, and increasing production efficiency.

Q2: Which printing machines can use this ultraviolet lamp?
A: The Albatross ultraviolet lamp is compatible with offset, flexo, gravure, digital inkjet, screen, and packaging printing machines.

Q3: Is this ultraviolet lamp suitable for high-speed printing operations?
A: Yes, it provides stable and consistent UV output, making it suitable for high-speed and high-volume printing lines.

Q4: Are multiple sizes of ultraviolet lamps available?
A: Yes, the ultraviolet lamp is available in around 200 standard sizes, and customized sizes can be manufactured to meet specific machine requirements.

Q5: Is the ultraviolet lamp easy to install?
A: Yes, with standardized end fittings, pin-type terminals, and flexible cable lengths, it can be easily integrated into most existing UV curing systems.

Adaptable Design for Every Printing Environment

The Albatross Ultraviolet Lamp is engineered with flexibility in mind. Compatible with both standard and custom mounting solutions, it integrates smoothly with numerous types of printing machines-from offset and gravure to digital inkjet. Thanks to its customizable dimensions, users can select an ideal fit based on their equipment, ensuring ease of installation across various production lines.

Long-lasting Performance and Reliable Protection

Benefit from an extended lamp life of up to 12,000 hours with high-performance quartz glass. The built-in over-voltage and thermal cut-off protection features provide peace of mind during prolonged operation. The polished or anodized surface finish adds durability, while air or water cooling options accommodate different industrial environments for optimal performance.

Energy Efficient and User-Friendly Operation

Albatross UV lamps are designed to match different power requirements, depending on lamp length and type, with voltage compatibility between 220 and 1900 volts. The hot/cold start ignition system and option for manual or automatic control enhance operator convenience. Maintenance and usage are simplified, making these lamps suitable for busy, high-output printing facilities.

FAQ's of Albatross Ultraviolet lamp:

Q: How do I choose the right Albatross UV lamp for my printing machine?

A: Selecting the right Albatross UV lamp depends on your specific printing machine model, required wavelength, and available mounting space. With customizable dimensions and both standard and custom mounting compatibility, you can configure the lamp to fit offset, flexographic, gravure, digital inkjet, and other printing systems. Our technical team can assist in selecting the ideal variant for your needs.

Q: What are the benefits of the quartz glass and aluminium housing used in the lamp?

A: Quartz glass provides excellent UV transmittance and thermal stability, enhancing the lamp's efficiency and lifespan. The aluminum housing offers lightweight strength and corrosion resistance, ensuring the lamp remains durable in demanding industrial environments.

Q: When should I replace my Albatross ultraviolet lamp?

A: The lamp typically lasts between 8,000 and 12,000 hours, but replacement time will depend on usage intensity and environment. It's advisable to monitor UV output regularly and replace the lamp when curing efficiency drops or at the end of its rated lifespan to maintain optimal print quality.

Q: Where can the Albatross UV lamp be installed?

A: This lamp is designed for installation in a range of printing and packaging machinery, including but not limited to offset printing machines, flexographic presses, gravure systems, digital inkjet equipment, and label finishing lines. Installation is straightforward with both standard and customizable mounting options.

Q: How does the lamp's protection system work?

A: The built-in over-voltage and thermal cut-off protection automatically shuts down the lamp in case of unsafe voltage levels or overheating. This prevents damage to both the lamp and printing machine, ensuring operator safety and extending equipment life.

Q: What is the process for customizing the lamp's dimensions or mounting?

A: You can specify your required length, width, height, and mounting preferences when placing an order. The manufacturer in India will tailor the lamp's size and provide mounting fixtures to ensure precise compatibility with your equipment.
